1000kg Batch Freeze Dryer
Product Details:
1000kg Batch Freeze Dryer Price And Quantity
- 1 Set
1000kg Batch Freeze Dryer Trade Information
- 10 Set Per Month
- 1 Week
Product Description
Our in-depth knowledge and industrial expertise has enabled us to emerge as a reputed manufacturer and supplier of 1000kg Batch Freeze Dryer. The vacuum system of this dryer has dual system; the pre-pumping unit and the maintenance unit, improve the stability and durability of the system. Our dexterous manpower uses quality grade materials to manufacture this dryer. This 1000kg Batch Freeze Dryer can be used in the drying of serum, plasma, vaccines, enzymes, hormones and so on.
Features:
- Longer service life
- Robust construction
- Maintenance free
Technical parameters of freeze dryer :
Model | EBT-1000 |
Type | Radiant type with individual quick freezer |
Ice Capacity (kg) | 1000kg in a 24hr period (vapor condenser capacity) |
Vapor Condenser Temperature (℃) | -45℃ (option: -60℃) |
Usable Shelf Area (m2) | 100.9 m2 |
Number of Shelves | 17+1, the top plate provides radiant heat only |
Shelf Dimension (mm) | 4950*(600*2)mm (thickness: 15mm) aluminum |
Shelf Spacing (mm) | 60-80mm |
Shelf Temperature (℃) | Room temperature to 110℃(max.) |
IQF Cooling Rate (+40℃ to –25℃) | ≤ 60 minutes |
Shelf Heating Rate (℃/min) (approx.) | 1℃/min, By electricity or steam |
Heating/cooling medium | Silicone oil or mixing liquid |
Heating/cooling exchange | By plate type of heat exchanger |
Number of Product Trays | 272 pieces |
Tray Dimension (mm) | 618*600mm (height: 25mm) aluminum |
Ultimate vacuum level (Pa) | 15 Pa |
Chamber vacuum rate (atm to 100 Pa) | ≤ 25 minutes |
Refrigeration | Brand option: Hanbell, Refcomb, Frascold, Bitzer. |
Refrigerant | R404A/R507 |
Cooling way | By water cooling or air cooling as option |
Cooling water flow rate | 90-110t/hr,<28℃ |
Vacuum system | Standard Yihua, Yoivac, Option: Ulvac/Edwards |
Energy consumption (24hr) | 3.27kWh/kg by water cooling |
Power requirement | 170.2kw, 110-240V single, 240-480V, 3P, 50/60Hz |
Defrost way | By water or 60°C hot water |
Control system | PLC with HMI |
Installation area (m2) | 200 m2 |
Chamber – over all dimension | 10800*2560*3200mm (L*W*H), SUS304 |
Weight (kg) | 18000kg |
