Lab Freeze Dryer
Product Details:
Lab Freeze Dryer Price And Quantity
- 350000.00 INR/Set
- 1 Set
Lab Freeze Dryer Trade Information
- 10 Set Per Month
- 1 Week
Product Description
We are engaged in offering a commendable range of Lab Freeze Dryer. Find extensive usage in pharmaceutical, chemical and many more industries, this dryer is well known among our clients who are situated across the nation. Besides being manufactured from well tested components and the latest technology, provided dryer is also properly checked by our quality controllers against several parameters. Owing to features like compact design, easy installation, high efficiency, smooth functioning and long working life, this dryer has exceptionally valued by our precious clients. The offered Lab Freeze Dryer are available with us in various specifications and at affordable prices.
LAB FREEZE DRYERS
It is applicable for food materials, Pharmaceuticals, Fruits, Vegetables, Mushroom, research products like microbial cultures, soil samples in geology. We supply the machines from the simplest table-top laboratory model 10N upto a pilot or industrial scale as per the need of the end-use. The condenser temperatures can be either -50 or -80, or a programmable high end models or a fully automated models for pharma applications with automatic loading and unloading facilities for vials. Of course the vials in our pilot and industrial models can be insitu-frozen and dryed completely. The complete turn-key projects can be undertaken by us for effective and user-friendly installations for 100% guaranteed out-put of the products even 1,2,3,5,10 metric tons of fruits and vegetable drying. We assure you the assured performance our freeze dryers inline to any imported models in the world.
EBT 10N Freeze Dryer -Lyophilizer
10N series freeze dryer, condenser lowest temperature -500C(80OC optional) CFC-free Refrigeration
Technical Specifications of EBT 10N:
| Model Type | EBT 10N Basic Type | EBT 10N Top-Stoper Down Type | EBT 10N Acrylic drum with multimanifolds type | EBT-10N 8=port acrylic drum manifold & vial stoppering shelf | EBT-10N 24-port column manifold (for flasks/ampoules) |
| No-load temperature | <-50oC(-80oC optional) | ||||
| Drying area | 0-12m2 | 0.09m2 | 0.12m2 | 0.09m2 | ......... |
| Plate load materials | 1.2L | 0.9L | 1.2L | 0.9L | ......... |
| Ability to capture water | 3kg/24h | ||||
| Dimension(mm) | 610x395x(370x420) | ||||
| Tray Size | 200mm Four Layered | 200mm Four Layered | 200mm Four layered | 200mm Four layered | ......... |
| Rated Power | 800w | ||||
| Voltage | 220v/50Hz | ||||
Standard Configurations EBT 10N:
| EBT-10N Basic Type | main machne, 2L/S Vacuum Pump, ordinary drying apparatus (3 sample tray) |
| EBT-10N Top-stoper down type | main machne, 2L/S Vacuum Pump, top-stoper down drying apparatus (3 sample tray) |
| EBT-10N Multi-manifolds type | main machne, 2L/S Vacuum Pump, multi-manifolds drying apparatus (4 sample tray, 8 Lyophilized bottle, 8 rubber valve) |
| EBT-10N top-stoper down & multi-manifolds type | main machne, 2L/S Vacuum Pump, to-stoper down drying apparatus (3 sample tray, 8 Lyophilized bottle, 8 rubber valve) |
| EBT-10N T-type ( for falsk or amouple) | main machne, 2L/S Vacuum Pump, 24 T-shaped frame rubber valve |
EBT 12N Freeze Dryer -Lyophilizer
12N series freeze dryer, condenser lowest temperature -500C(80OC optional) CFC-free Refrigeration
Technical Specifications of EBT-12N:
| Model Type | EBT 12N Basic Type | EBT 12N Top-Stoper Down Type | EBT 12N Acrylic drum with multimanifolds type | EBT-12N 8=port acrylic drum manifold & vial stoppering shelf | EBT-12N 24-port column manifold (for flasks/ampoules) |
| No-load temperature | <-50oC(-80oC optional) | ||||
| drying area | 0-12m2 | 0.09m2 | 0.12m2 | 0.09m2 | ......... |
| Plate load materials | 1.2L | 0.9L | 1.2L | 0.9L | ......... |
| Ability to capture water | 4kg/24h | ||||
| Dimension(mm) | 800x515x(725x420) | ||||
| Tray Size | 200mm Four Layered | 200mm Four Layered | 200mm Four layered | 200mm Four layered | ......... |
| Vacuum | <10Pa | ||||
| Rated Power | 1000w | ||||
| Voltage | 220v/50Hz | ||||
Standard Configurations of EBT-12N:
| EBT-12N Basic Type | main machne, 2L/S Vacuum Pump, Basic drying apparatus (4 sample tray) |
| EBT-12N Top-stoper down type | main machne, 2L/S Vacuum Pump, top-stoper down drying apparatus (3 sample tray) |
| EBT-12N Multi-manifolds type | main machne, 2L/S Vacuum Pump, multi-manifolds drying apparatus (4 sample tray, 8 Lyophilized bottle, 8 rubber valve) |
| EBT-12N top-stoper down & multi-manifolds type | main machne, 2L/S Vacuum Pump, to-stoper down drying apparatus (3 sample tray, 8 Lyophilized bottle, 8 rubber valve) |
| EBT-12N T-type ( for falsk or amouple) | main machne, 2L/S Vacuum Pump, 24 T-shaped frame rubber valve |
